Unity ELITE 3 PRO FB4

Name: Unity ELITE 3 PRO FB4
Brand: end user
Price: 2375.0 EUR
Availability: InStock

Unity Elite 3 PRO FB4 lasers is our top-of-the-range laser system with the integrated Pangolin FB4 media server.

Elite 3 PRO FB4 laser is ideal for clubs, lighting designers and special effects and rental companies who prefer direct control of their lasers over DMX and Artnet.
All systems use semiconductor laser diodes, are full-colour RGB with analogue modulation, and are integrated into robust housing. They are suitable for permanent installations in clubs, touring and rental situations.

The Elite 3 PRO FB4 is suitable for small-to-medium-sized indoor venues and events.

Unity ELITE PRO FB4 Series | 3-5 Watt Lasers for Lighting Designers

What is in the Package

Heavy-duty flight case

Laser control software

Laser projector

Mains cable

Ethernet cable

E-STOP Remote

E-STOP XLR cable

Set of 4 Safety keys

Quality certificate

Interlock [for the US only]

Specifications

Product Name:	Unity ELITE PRO 3 FB4
Type Of Laser:	Full-colour, Semiconductor diode laser system
Guaranteed Optical Output:	>3.1W
Suitable For:	Lighting professionals: medium indoor venues, clubs, theater, house of worship, gymnasium (up to 3,000 people). Beam show, text, graphic, and mapping capable
Control Signal:	Pangolin FB4 DMX [Ethernet, ArtNet, DMX, sACN, ILDA \| PC, Lighting Console, Auto Mode, Mobile App: Apple, Android]
Scanning System:	30,000 points per second @ 8°
Scan Angle:	50°
Safety:	Fully complies with the latest EN 60825-1 and FDA regulations
Weight:	8kg
Package Includes:	Laser projector w/ FB4 DMX, protective case, Estop box, Estop cable (10M/30ft), ethernet cable (10M/30ft), power cable (1.5M/4.5ft), interlock (* service dongle if outside US), keys, manual, quickstart guide, variance card
R \| G \| B [mW]:	610 \| 800 \| 1,760
Beam Size [mm]:	2 x 4
Beam Divergence:	<1mrad [Full Angle]
Modulation:	Analog 100kHz
Power Requirements:	100-230V/50Hz
Consumption:	Max. 150W
Operation Temperature:	10-40 °C
Ingress Rating:	IP4X
System Features:	All the adjustments, such as power output of each color, X & Y axes invert, X & Y size and position, safety, etc., are managed digitally by the FB4 control system. Ethernet in, power in/out, DMX in/out, Estop in/out
Laser Safety Features:	Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate
Notice:	*Due to Advanced Optical Correction technology used in our laser systems, each laser colour's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output
Dimensions [mm]:	Depth: 238 \| Width: 246 \| Height: 175
